- CAUTION

1. CARBON FILTER FLUSHING

    After the installation or changing carbon filter, Manual Flushing Valve shall be opened for

    2~3 min before operation. (process: water flow for 2~3 min)

2. AUTO FLUSHING (RO MEMBRANE)

- INSTALLATION STEP

1. Tubing connections on the back of products should be connected with each usage (Inlet Water, Drink Water, Tank, Drain).

    But, If the tank is not a pressure tank, water, level switch must be set the tank separatly.

2. Carbon filter need to be flushing with manual flushing valve for 2~3 min the initial installation.

3. Set the local time of timer for BYPASS and BYPASS TIME you want.

4. Turn on the system.

5. Once pressure tank is filled up water and the system is automatically stopped, Faucet shall be opened and

    the stored water shall be out of the tank.

- RO MEMBRANE

Membrane Type: Polyamide Thin-film Composite

Maximum Operating Temperature: 113 F (45 C)

Maximum Operating Pressure: 125 psi (8.6 bar)

Permeation flow rate(GPD) of RO membrane depends on the quality of raw water.
